Repeat AM32 Dual Brushless Drive ESC

$45.00
$50.00 $45.00
Save $5.00

Looking for something to simplify the wiring of your robot? The Repeat AM32 Dual Brushless Drive ESC makes the insides of your bot neat and tidy while delivering high performance in a tiny package. Running the latest AM32 software, this ESC punches above its size.

BACKORDER STATUS:

ESCs came with default AM32 settings so I will be re-flashing them on demand as I work on a way to flash them in bulk.Orders with am32 dual escs may be delayed for 2-3 days for flashing.
Availability: Low stock: 10 left
Repeat AM32 Dual Brushless Drive ESC image 0
$45.00
$50.00 $45.00
Features
  • V1.1 comes with castellated pads for soldering the motors to
  • Pre-programmed with drive settings
  • Small size - 28 x 20 x 5 mm
  • Light Weight - (6g with signal wires)
  • Active current limiting on each channel (Comes with current limit set at 10A)
  • 2-6S voltage capacity
    • Comes with capacitor for 6S usage
  • Comes with BEC to power your receiver
  • Power pads on both sides of the board allow you to solder your weapon ESC to the bottom side of the board
  • Equivalent components to 45A drone ESCs
  • Does not have mixing ability
  • Suitable for 1lb to 3lb robots
    • Suggested 4A-8A current limit for 1lb-3lb robots
    • Can be used in larger robots with appropriate current limits
Find the most up to date version of the AM32 configurator tool here: https://am32.ca/downloads Look for the profile for AM32_RR_ROBOT_DUAL_ESC_F421
