Catalyst Dual Brushless esc with Integrated radio

$65.00
$65.00

An all-in-one brushless DESC with integrated AFHDS 2A radio.
Availability: In stock
SKU: RR-03-3343
Collections:
Repeat RoboticsBeater Bar Parts
Repeat Beater Bar Parts image 0
ToolkitRC WM150 Power Meter image 0
Misc. ElectronicsToolkitRC WM150 Power Meter
$65.00
$65.00
  • Input Voltage: 2–6S*
  • Dimensions: 19 × 29 × 5 mm
  • Weight: 4 g
  • Antenna: Compact 2.4 GHz chip antenna
  • Pads: Castellated for easier soldering
  • Equivalent Components: 45 A ESCs
  • Firmware: AM32 ESC (preconfigured, user-configurable)
  • Radio Protocol: AFHDS 2A
  • PWM Outputs: 2 (for weapon ESCs or servos)
  • Supports: Mixing and AUX switch for inverting controls
  • Recommended Robot Weight: 1 lb – 3 lb

*Note: 6S requires external capacitor and spike absorber

User manual and documentation: https://github.com/CronosLabsTech/Catalyst-MK1/wiki
