Repeat Gold Foam Eco Hub (2pcs)

$14.00 - $15.00

Need a cheap way to attach foam wheels to your bot? Want gold rims on your next bot? Repeat Foam Eco Hubs are here! Designed for maximum performance at a low price, these hubs look great while doing it! Now with a second generation design boasting several improvements on the first version!

Hole Size: 3mm
Wheel Thickness: 0.50"
$14.00
$14.00
Availability: 207 in stock
Repeat RoboticsRepeat Gold Clamp Hub (2pcs)
Repeat Gold Clamp Hub (2pcs) image 0
Peter Bar Weapon kit image 0
Repeat RoboticsPeter Bar Weapon kit
Repeat Gold Foam Eco Hub (2pcs) image 0
$14.00
$14.00

Mk2

  • Made from gold anodized 6061-T6 aluminum
  • End plate screws in with 2x M3 x 8mm flathead screws
  • 0.75" size hubs are held onto the shaft with 2x oversized M4 x 4mm setscrews
  • 0.5" size hubs are held onto the shaft with 1x oversized M4x4mm setscrews
  • Come with holes for 3mm or #4 screws to mount a pulley to the inside of the hub
  • Made for either 0.5" or 0.75" thick foam wheels
  • New: Chamfer added to make installation easier
  • New: Changed spline pattern to reduce wheel deformation
  • New: Added rib on inner surface to prevent rubbing on chassis
  • Weight
    • 3mm x 0.50" - 13.7g
    • 4mm x 0.50" - 13.4g
    • 3mm x 0.75" - 17.85g
    • 4mm x 0.75" - 17.4g
    • 6mm x 0.75" - 17.45g
Purchase comes with 2 pcs gold hub. Find the V2 3D model here: https://grabcad.com/library/repeat-gold-eco-hub-mk2-1
